Canon EF 20mm f/2.8 USM : Specifications and Opinions

Canon EF 20mm f/2.8 USM

The Canon EF 20mm f/2.8 USM is a wide-angle lens for FF and APS-C, manufactured from 1992 to 2020 (discontinued). The focus is done by Ultrasonic AF Motor (Ring-USM), it does not have image stabilization. The average price was 339 €;

23 users have given it an average vote of 8.7 out of 10.

MOUNT

This lens is available with the following mounts:

Canon EF: this lens is compatible with reflex fullframe and APS-C Canon EF.

Specifications
Focal lenght	20 mm
Angle of view	94.5°
Format	FF, APS-C
Max. aperture	f/2.8
Aperture blades	5
Lenses/Groups	11 elements in 9 groups
Min. focus distance	0.25 meters
Reproduction ratio	0.14x
Features
Stabilization	No
Focus	Ultrasonic AF Motor (Ring-USM)
Internal Focus	Yes
Built and notes
Tripod ring	No
Extenders	No
Filters	72 mm
Lens hood	Yes (not supplied)
Weather sealing	No
Weight	405 g
Dimensions	78 x 71 mm
Buy
Canon EF 20mm f/2.8 USM, buy on Ebay JuzaPhoto contains affiliate links from Amazon and Ebay and JuzaPhoto earn a commission in case of purchase through affiliate links.

Publish your advertisement on JuzaPhoto (info)

Reviews

What do you think?

Do you want add your opinion? You do it by joining JuzaPhoto, it is easy and free!

There is more: by registering you can create your personal page, publish photos, receive comments, join discussions and you can use all the features of JuzaPhoto. With more than 259000 members, there is space for everyone, from the beginner to the professional.

The following opinions have been automatically translated with Google Translate.

Peppe Cancellieri

sent on 23 Gennaio 2026

Pros: Construction, fairly compact, sharp enough

Cons: Lens hood

Opinion: I have resurrected this very old lens which is worth much more than the 160 euros I paid for it. The shots at 20mm are quite different from those of a 24mm and for this reason I wanted to put it back in the kit, there are not many 20mm around and certainly none at that price. I'm very satisfied with it for that vaguely vintage air but also for the colors, sharpness, AF and also quite bright. In short, everything is fine except for the "usual" lens hood that is not there and an original one costs almost more than the lens, an inexplicable issue at Canon. I have a compatible one but it doesn't mount well so you can see flaps in the frame and you can't use it, I'll try with a universal screw one or I'll do without it. Rating about 9

DiegoD

sent on 20 Marzo 2020

Pros: Compact - AF fast - blurry

Cons: Tropicalization

Opinion: If this project has not been updated or changed there are 2 reasons: the first is the fact that the lens does more than excellently its duty as it is, the second is that although it is not perfect, it represents a bright fixed at ridiculous costs (for the focal FF) usable in all excluding architecture. It may not be monstrous at the corners, but it certainly has a pleasant yield and blurry one. if I had to give a definition I'd say it's a Canon. And by that I mean that it's a lens whose photos stand out, have character and personality, are not sharp at the edges and do not even have any distortion, but the outcome is pleasant. It generates poetry and atmosphere as long as you devote time to it. Beautiful focal on aps-c

Giuseppe Patruno

sent on 26 Novembre 2019

Pros: Brightness, accuracy and AF speed, sharpness already from f2.8, blurred, minimum focus distance, general yield, flare resistance, little distortion, cost

Cons: Optics a little forgotten and very underestimated, it could have become perfect if it had been F2, good but discreet flare resistance compared to other optics such as the 17-40

Opinion: Recently purchased and impressed me immediately... a lens that in my opinion can satisfy many genres, from landscapes to the street, up to portraits and ceremonial works... its speed and precision, even on machine bodies with not fast and recent focus make it suitable for "fast" and silent situations.... a blurry then gorgeous for such a wide focal, sharp already slightly at 2.8, closed at 3.2 or 3.5 already makes much more... to very closed diaphragms it retains well its resistance to flare, which really amazed me, overall then has a pasty and delicate yield, it is not an L series of course but by its standards you can work very well professionally, for less than 350 euros I highly recommend it to everyone !

Sandrofoto

sent on 23 Luglio 2019

Pros: Construction, sharpness from f4, to 2.8 good, very low distortion, soft color yield, vintage colors

Cons: Vignette, backlight in critical situations

Opinion: I say that I use it on 6D, I honestly found it very good, on the web the vast majority talk about it very badly, I do not understand what parameters of observation are made. Natural colors not contrasted, shadows not closed, low distortion, excellent sharpness from f4, by necessity you can safely use even at 2.8, in short for me it is a very good lens so I completely disassociate myself from the negative comments of others. The construction, although not an L-series, is dignified and robust. On the other hand, the vignette is elevated to the most open diaphragms but it is corrected in a quiet click, and the backlight but only in really critical situations, sun in the frame. I recommend it, low price especially in the used and excellent quality in general.

Mauro57

sent on 16 Novembre 2017

Pros: construction, chromatic rendering, distortion

Cons: slight loss of sharpness and vignetting at the extreme corners only with full frame

Opinion: Great focal length of 20mm, it allows a little bit of detail to frame virtually everything without distortion, this particular that I use for a long time returns a chromatic tonality in the wonderful interior, good focus with center point on both 5D old and 6D, excellent sharpness in the middle and discreet on the edges, it only smacks a slight vignetting and sharpening but only in the extreme corners with full frame.

There are 5 more reviews. Show all »
